Network Video Recorder 64 Channel
64 Channel NVR, Quad Core, 320Mb Bandwidth, 4K Video Output, RAID 0, 1, 5, 10, H.264 Zip+, H.265 Ready
- 64 Channel Network Video Recorder
- Support Live View, Recording, Playback up to 12MP IP Camera
- Quad-core CPU
- 320Mb Bandwidth
- 4K (3840x2160) HDMI Video Output
- 8 SATA up to 6TB each HDD
- 2 RJ45 10/100/1000Mbps Ethernet Interfaces
- RAID 0, 1, 5, 10 Hot Swap
- H.264/H.264 Zip+/H.265 Ready
Specification:
| Recorder Series |
High Density Series |
| Recorder Channel |
64-Channel |
| Recorder Case |
2U Case |
| Recorder Technology |
IP / NVR |
| Featured Product |
No |
| Specifications |
| Video/Audio Input |
| IP Video Input |
64-CH
Up to 12MP resolution |
| Two-Way Audio Input |
1- ch, RCA (2.0 Vp- p, 1kΩ) |
| Network |
| Incoming Bandwidth |
320Mbps or 200Mbps(When RAID is enabled) |
| Outgoing Bandwidth |
256Mbps or 200Mbps(When RAID is enabled) |
| Remote Connection |
128 |
| Video/Audio Output |
| Recording Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/QCIF |
| VGA1/HDMI1 output |
HDMI1: 4K(3840×2160)/60Hz,4K(3840×2160)/30Hz,2K(2560×1440)/60Hz,1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1 280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz;
VGA1: 2K(2560×1440)/60Hz, 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 ×1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| VGA2/HDMI2 output |
1920 × 1080P /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio Output |
2- ch, RCA (2.0Vp-p,1kΩ) |
| Decoding |
| Decoding Format |
H.265/H.264+/H.264/MPEG4 |
| Recording Resolution |
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/QCIF |
| Synchronous Playback |
16-ch |
| Hard Disk |
| SATA |
8 SATA interfaces for 8HDDs |
| eSATA |
1 eSATA Interface |
| Capacity |
Up to 8TB capacity for each HDD |
| Disk Array |
| Array Type |
RAID0, RAID1, RAID5, RAID6,RAID10 |
| Number of array |
4 |
| Interface |
| Network Interface |
2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces |
| Serial Interface |
RS-232; RS-485; Keyboard; |
| USB Interface |
2 × USB 2.0 on front panel and 1× USB 3.0 on rear panel |
| Alarm In/Out |
16/4 |
| General |
| Power Supply |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption |
≤ 30 W(without hard disk) |
| Working Temperature |
14°F - 131°F(-10 °C ~ +55 °C) |
| Working Humidity |
10% - 90% |
| Casing |
19-inch rack-mounted 2U chassis |
| Dimension |
17.5" ×18.5"×3.5"(445 × 470 ×90 mm) |
| Weight |
≤ 22 lb (10 Kg,without hard disk) |
|
