| Video/Audio Input |
| IP Video Input |
256-CH,Up to 8MP Resolution |
| Two-Way audio Input |
1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network |
| Incoming Bandwidth |
640Mbps, or 400Mbps (When RAID is Enabled) |
| Outgoing Bandwidth |
400Mbps |
| Remote Connection |
256 |
| Video/Audio Output |
| Recording Resolution |
8MP/6MP/5MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| HDMI1/VGA1 Output Resolution |
1-ch,
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
| HDMI2 Output |
1-ch,
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
| HDMI outputs (on HDMI Output Extension Board) |
1-ch,
1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768/60Hz |
| Audio Output |
1-ch, RCA (Linear, 1kΩ) |
| Decoding |
| Live View/Playback Resolution |
H.264, MPEG4, M-JPEG |
| Synchronous Playback |
16-CH |
| Capability |
44-ch@1080P |
| Hard Disk |
| SATA |
16 SATA Interfaces for 16HDDs |
| Capacity |
Up to 6TB Capacity for Each HDD |
| Disk Array |
| Array Type |
RAID0, RAID1, RAID5, RAID10 |
| Number of Array |
16 |
| Interface |
| Network Interface |
4 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet Interfaces |
| Optic Fiber Interface |
4, 1000 Mbps Optic Fiber Interface |
| Serial Interface |
RS-232; RS-485; Keyboard |
| USB Interface |
2 × USB 2.0 on Front Panel and 2 × USB 3.0 on Rear Panel |
| Alarm In/Out |
16/8 |
| General |
| Power Supply |
100 ~ 240 VAC, 50 ~ 60 Hz |
| Consumption |
≤ 100 W (Without Hard Disk or DVD-R/W) |
| Working Temperature |
14ºF ~ 131ºF(-10 ºC ~ +55 ºC) |
| Working Humidity |
10% ~ 90% |
| Casing |
19-Inch Rack-Mounted 3U Chassis |
| Dimensions (WxDxH) |
17.4" ×19.4"×5.7"(442× 494 ×146 mm) |
| Weight |
≤ 34.2 lb (15.5 Kg,without hard disk or DVD-R/W) |
